Features
Legendary Tracking System
Summa's exclusive MicroSprocket drive drum, coupled with powerful servo motors, deliver jaw-dropping accuracy. Media is conditioned as it advances to assure spot-on tracking precision.
OPOS Contour Cutting Alignment
The automated contour alignment system OPOS stands for Optical Positioning System. The OPOS X sensor technology senses a minimum of 4 and a maximum of 128 marks on a wide range of materials. Some of its features include a fully-automated workflow, using OPOS barcodes, enabling you to contour cut multiple jobs without intervention.
Vibrant Color Touch Screen
The intuitively redesigned menu system and full-colour touch interface allow for effortless navigation. Tactile and easy to use, the touch screen displays large amounts of information in an easily accessible format.
Unmatched Die-Cutting Precision
Summa's unique FlexCut feature takes cutting technology to the next level. This adjustable feature creates a perforated cut that allows the material to retain the necessary rigidity to transport through the cutter while remaining easy to break apart into individual pieces.
Automatic Cut-off knife
The cutting head includes an automatic cut-off knife which can optionally be set as to slice your media at the end of the job.
Ethernet Connectivity
Multiple computers can now control one unit across a network, or a crossover cable can be used for direct connection - creating an all-new avenue for faster communication and data transmission speeds.
A Servo-powered Roll-up System for Summa S Class 2 140 and Summa S Class 2 160
After a job is finished, the system will roll up the artwork neatly and prepare the machine for the next unattended job. The integrated paneling feature splits long-length runs into shorter consecutive jobs.
Specifications
CUTTING TYPE: True Tangential with Drag Knife Cutting Mode Capability
CUTTING WIDTH: 29 inch (74 cm), (Extended Mode: width of the material)
CUTTING SPEED: All Summa S2 models cut at speeds up to 56 inches per second diagonal
AXIAL SPEED: Up to 4 G
ALIGNMENT TYPE:
- OPOS - CAM : Factory upgrade on all new Summa S Class 2 S160T
- Barcode job recognition
- Up to 2 x 64 marks on the X-line
- Y-Line compensation
MAXIMUM ACCELERATION: Up to 5.5 G diagonal
TRACKING PERFORMANCE:
Within +/- 0.004 in. (+/- 0.1 mm) on plots up to 40 ft. (12 m) long on rolls up to 760 mm wide
Within +/- 0.004 in. (+/- 0.1 mm) on plots up to 13 ft. (4 m) long on rolls over 760 mm wide
CUTTING FORCE: 0-600 grams of down-force, in 5 gram increments
DISPLAY LANGUAGES: English; French; German; Dutch; Italian; Spanish; Polish; Czech; Latvian; Lithuanian; Portuguese
CONNECTIVITY: USB, Ethernet
POWER REQUIREMENTS: 100-120 / 220-240 VAC, 50/60 Hz, 85 VA maximum
DIMENSIONS: 141 (W) x 68 (D) x 111 (H) cm 55.5 (W) x 26.8 (D) x 43.7 (H) in.
WEIGHT: 152 lbs (69 kg)
OPERATING TEMPERATURE: 59˚ to 95˚F (15˚ to 35˚C)
STANDARD ACCESSORIES: WinPlot or MacSign Cut Software, CutterControl Parameter Software, CD w/ Manuals and Drivers, Quick Start Guide, Power Cable, USB Cable, Media Guide Flanges (set of 2), 1 Spare Fuse, Standard 36˚ Blade Holder, 2 Standard 36˚ Blades, Cut-off Knife (Manual Slitter), 2 Cut-off Razor Blades, Pouncing Pin and Holder, Stand and Basket.
OPTIONAL ACCESSORIES:
