Persimmon Oracal 631 12" x 12" Sample Sheet

Description
Soft PVC film that features a matte surface to suppress unwanted reflection and residue-free removal for two years.



Release Paper
83# custom silicone-coated paper with special release characteristics that provide excellent weeding and release values. Customized blue silicone paper liner for white provides superior contrast for cutting and weeding.



Adhesive
Polyacrylate dispersion, removable



Areas of Use
Due to its special release characteristics, it is ideal for use in computer-aided signmaking (CAS) equipment. For short- and medium-term outdoor applications in display and exhibition stands. Certified according to DIN 4102-B1.



Thickness
(without protective paper and adhesive) 3 mil



Dimensional Stability
(FINAT-TM 14) adhered to steel, no shrinkage in cross direction, in length <.016"



Temperature Resistance
adhered to aluminum, -40 deg F to



Adhesive Power
(FINAT-TM 1, after 24 h, stainless steel, average) 1.65 lb/in



Outdoor Durability
( )



Shelf Life
(68 deg F/50% relative humidity)



Seawaterability
adhered to aluminum, no variation after 48 h/73 deg F



Elongation at break (across)
(DIN EN ISO 527) min.150%



Elongation at break (along)
(DIN EN ISO 527) min.130%



Tensile Strength (across)
(DIN EN ISO 527) min. 19 MPa



Tensile Strength (along)
(DIN EN ISO 527) min. 19 MPa



Resistance to solvents and chemicals
After 72 hours adhered to aluminum at room temperature, resistant to most oils and greases, weak acids, salts and alkalis



Removability
residueless removal within 2 years



Minimum application temperature
+50 deg F



Surface finish
matte



Number of Colors
62



Indoor Durability
(based on vertical surface exposure) 3 years
